Output

  • 4-20 mA with digital signal based on HART Protocol

  • Low Power, 1-5 V dc with digital signal based on HART Protocol

  • FOUNDATION fieldbus, PROFIBUS®

Range

  • Up to 10000 psig (689,47 bar) Gage

  • Up to 10000 psia (689,47bar) Absolute

  • 30, 150, 800, 4000and 10,000 psi

Accuracy

  • Up to ±0.05% of span

  • 0.075%, optional 0.065%

Power

  • 4-20 mA: 10.5-42.4 V dc with no load

  • Low Power: 6-12 V dc with no load

Process Wetted Material

  • 316L SST

  • Alloy C-276

Features

  • In-line gage and absolute pressure measurements support up to 10000 psi (689,47 bar) for pressure and level solutions

  • Delivered fully assembled to manifolds or diaphragm seals for straightforward installation

  • Intuitive Local Operator Interface streamlines commissioning for simple and cost-effective installation

  • SIL 2/3 certified to IEC 61508 (via 3rd party) and prior-use certificate of FMEDA data for safety installations

  • 316L SST and Hastelloy C-276 process wetted parts
