Microwave output power: Nominal 300 μW, Max. 45 mW
Telecommunication: (FCC and R&TTE), FCC part 15 (1998) subpart B and R&TTE (EU directive 99/5/EC)
Humidity: 0 - 100% Relative Humidity
Start-up time: < 40s
Signal wiring: Recommended output cabling is twisted shielded pairs, 24-12 AWG
Accuracy: ± 0.12 in. (3 mm)
Repeatability: ± 0.04 in. (1 mm)
Measurement Range: Up to 164 ft (50 m)
Operating Pressure: Full vacuum to 5000 psi (Full vacuum to 345 bar)
Operating Temperature: -320 to 752 °F (-196 to 400 °C)
Communication Protocols: 4-20 mA/HART™, Foundation™ Fieldbus, Modbus™
Safety: SIL 2 IEC 61508 certification, TÜV tested, remote testing capabilities, overfill prevention feature
Probe Types: Rigid single lead, segmented single lead, flexible single lead, rigid twin lead, flexible twin lead, coaxial and large coaxial, PTFE coated probes, vapor probe
Warranty: Up to five years
